Widely used new GR135 small motor grader for sale

FOB Reference Price:Get Latest Price
$42,000.00 - $53,000.00 / Unit | 1 Unit/Units (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Forward Speed(km/h):
23
Reverse Speed(km/h):
38
Condition:
New
Place of Origin:
Jiangsu, China
Brand Name:
xg
Model Number:
GR135
Weight:
11000kg
Certification:
ISO
Dimension(L*W*H):
8015*2380*3050mm
Color:
Yellow
Rated power:
100kw/135HP
Blade width:
3710mm
Max. gradeability:
30%
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
100 Unit/Units per Month
Packaging & Delivery
Packaging Details
container roro bulk break shipment
Port
shanghai
Lead Time :
7-10days

Widely used new GR135 small motor grader for sale

Feature

GR Series Motor Graders are mainly used in ground leveling ,canalling , slope scraping ,earthmoving ,scarification or snow removal work on road, airfield ,farmland ,and so on .They are necessary construction machines for national defense engineering ,mine construction, town and country roads building ,and farmland improvement.

Performance and characteristic



Parameters



Basic specification

Engine model

6BT5.9

Rated power/speed

100/2200kw/rpm

Dimension(LxWxH)

8015×2380×3050mm

Operating weight(Standard)

11200kg

Performance specification

Travelling speed ,forward

5,8,13,20,30,42km/h

Travelling speed ,reverse

5,13,30km/h

Tractive force(f=0.75)

61.3KN

Max. gradeability

30%

Tire inflation pressure

300kPa

Working hydraulic pressure

16MPa

Transmission pressure

1.3~1.8MPa

Operating specification

Max. steering angle of front wheels

±49°

Max. lean angle of front wheels

±17°

Max. oscillation angle of front axle

±15°

Max. oscillation angle of balance box

16

Frame articulation angle

±27°

Min. turning radius using articulation

6.6m

Biade

Maximum lift above ground

410mm

Maximum depth of cutting

515mm

Maximum blade position angle

90°

Blade cutting angle

54°—90°

Circle reversing rotation

360°

Moldboard width X height

3710×610mm
