Liugong 140HP widely used CLG414 motor grader price

FOB Reference Price:Get Latest Price
$40,000.00 - $60,000.00 / Units | 1 Unit/Units (Min. Order)
Model Number:
CLG414
Weight:
12800 kg
Shipping:
Support Sea freight
Lead Time:
Quantity(Units) 1 - 1 >1
Est. Time(days) 15 Negotiable
Report Suspicious Activity
Overview
Quick Details
Forward Speed(km/h):
38
Reverse Speed(km/h):
23
Warranty:
1 Year
After-sales Service Provided:
Overseas service center available, Engineers available to service machinery overseas, Overseas third-party support available
Condition:
New
Place of Origin:
Guangxi, China
Brand Name:
Liugong
Dimension(L*W*H):
8340 *2465 *3370 mm
Certification:
ISO CE
Rated Power:
109 KW (148 hp)
Maximum Speed:
41 km/h
Draw Bar Pull:
65 kN
Blade Width:
3660mm
Supply Ability
Supply Ability:
30 Unit/Units per Month
Packaging & Delivery
Packaging Details
by container or by roro or by bulk break shipment
Port
Shanghai
Lead Time :
Quantity(Units) 1 - 1 >1
Est. Time(days) 15 To be negotiated
Product Description

Liugong 140HP widely used CLG414 motor grader price

Engine DCEC 6BTAA5.9-C180
Rated Power (kW)125(170)@2200
Blade Width mm(inches)3960(156)
Maximum Speed km/h (mph)38 (23.6)
Draw Bar Pull(kN)81.6
Operating Weight kg(Lb)15000

TRANSMISSION
Transmission Type power shift
Transmission Configuration 6f/3r
Torque Converter three-member single turbine
Maximum Travel Speed, fwd(km/h)38
Maximum Travel Speed, rev(km/h)24.7
Number of Speeds, fwd 6
Number of Speeds, rev 3
AXLES
Front Axle Make  LiuGong Weld axle
Rear Axle Make  Meritor
Differential Type NO-SPIN limited slip standard
Final Drive Type chain drive
Axle Oscillation ±15°
Front Axle Type all welded steel frame
Front Axle, Wheel Lean Angle ±17°

DIMENSIONS
Wheelbasemm(inches)6230(245)
Overall Lengthmm(inches)8790(346)
Overall Height with Cab 3438(135)
Overall Widthmm(inches)2600(102)
Clearance under Front Axlemm(inches)645(25)
Moldboard Standard Lengthmm(inches)3960(156)
Moldboard Standard Thicknessmm(inches)19(0.7)
Moldboard Standard Heightmm(inches)610(24)




Built for Efficiency



1.World-class  engine with high power and low fuel consumption.



2.Scraping knife has 360 degree rotation, 90 degree right/left lateral adjustment, and 40-70 degree penetration for leveling, trenching, ditching, wall scraping and more.



3.LiuGong designed suction cooling system has better cooling, lower wind sensitivity and is less impacted by dirt than normal systems.



4.Meeting EU stage II/EPA tier 2 emission standards.



Easy to Maintain



1.Hydraulic pipes on both sides of frame for easy maintenance.



2.Easy engine access and access to main maintenance points



Reliability



1.Power cuts off if hand brake not removed, this prevents accidental damage.



2.Parts, service and attachments you can count on.



World-class suppliers of key components.



Operator Comfort and Safety



1.Dustproof, sound reducing, shock absorbing and anti-UV cabin.



2.Comfortable adjustable suspension seating.



3.Air Conditioning optional.



4.Full range of visibility.
