NEWINDU 16ton tyre road roller XP163

FOB Reference Price:Get Latest Price
$55,000.00 - $60,000.00 / Unit | 1 Unit/Units (Min. Order)
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Power(W):
110KW
Travel Speed:
0-20km/h
Static Linear Pressure:
385N/cm
Condition:
New
Place of Origin:
Henan, China
Brand Name:
NEWINDU
Model Number:
XP163
Certification:
ISO9001
Type:
Tire Roller
Dimension(L*W*H):
4770x2210x3443mm
Grade Ability:
20%
Static linear load:
11000KG
Min. ground clearance:
250mm
Grade ability:
20%
Turning radius:
7230mm
Diesel model:
YC4A125Z
Operating mass:
16000kg
Hydraulic oil tank capacity:
60L
Fuel tank capacity:
130L
Other character:
NEWINDU 16ton tyre road roller XP163
Weight:
26000kg
After-sales Service Provided:
Engineers available to service machinery overseas
Supply Ability
Supply Ability:
20 Unit/Units per Month
Packaging & Delivery
Packaging Details
Nude-packing
Port
Shanghai
Lead Time :
30 days after receiving deposit
Product Description

 NEWINDU 16ton Tyre road roller XP163 model





Driving comfort
Spacious and bright cab features wide view and comfort. Both-side operation can absolutely avoid rolling the curb and the compacting blind corners.
Simple operation
There are two steering wheels, two seats, and two independent control systems for operations. The speed change adopts electric control handle and two-speed gear shift design, which can respectively meet the requirements of compaction and site transfer, together with flexible electronic control operation and comfortable handfeel, greatly reduces the labor intensity of the drivers.
Excellent performance
Adopting the pneumatic tyre to compact the layer will not damage the compacted materials. The compact performance can be improved by adding or reducing the counterweight and changing the inflation pressure of the tyres. Because of the kneading effect produced by the tyre’s elasticity, the material displacement will be produced in all directions, forming even dense surface without cracks, which can prolong the service life of the road.
Adopt the front wheels swing mechanism. When the machine works on rough road, the mechanism ensures the even ground pressure, which can make the materials be compacted evenly.
The optional international leading infrared tyre heating system realizes the no water sprinkling work of the compactor, and improves the density and service life of the road.
Unique structure
The transmission system adopts the hydraulic transmission with infinitely variable speeds. The start of the torque converter and the speed change are stable and without impact, reducing the shear stress to the road, and improving the compacting quality. The torque converter adopts hydrodynamic drive, which makes the compactor have adaptivity, ensures the diesel engine and the transmission system work under the rated working condition, and prolongs the service life of the compactor.



TypeUnitXP163
Operating weightkg11100
Max operating weightkg16000
Travel Speed, Forwardkm/h4.2 , 8.2 , 17.4
Travel Speed, ReverseKm/h4.2, 8.2
Gradeability in theory%30
Minimum outer turning radiusmm7230
Min ground clearancemm250
Compacting widthmm2055
Overlapping of front&rear tyremm30
Tire specification 9.0-12-20PR
Number of tyres 4 front & 5 rear
Ground pressurekPa200-400
Engine Model YC4A125Z
Rated rotating speedr/min2200
Rated powerkW92
Engine oil consumptiong.kw/h>230
Dimensions(LxWxH)mm4770x2210x3442
Fuel tank capacityL130
Hydraulic oil tank capacityL60



 QQ20161205104012.jpgQQ20161205130045.jpgQQ20161205130051.jpgQQ20161205130054.jpgQQ20161205130056.jpg
