Big Discount Sany GR180 120h motor grader grader gd511

FOB Reference Price:Get Latest Price
$9,800.00 - $10,000.00 / Sets | 1 Set/Sets (Min. Order)
Model Number:
GR180
Weight:
15400kg
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Forward Speed(km/h):
23
Reverse Speed(km/h):
38
Warranty:
1 Year
After-sales Service Provided:
Overseas service center available, Engineers available to service machinery overseas, Overseas third-party support available
Condition:
New
Place of Origin:
Shanghai, China
Brand Name:
NEWINDU
Dimension(L*W*H):
8900x2625x3470mm
Certification:
ISO
Engine Model:
6CTAA8.3 D6114
Rated Power:
138/2200kw/rpm
Maximum lift above ground:
450mm
Maximum depth of cutting:
500mm
Blade cutting angle:
28°-70°
other character:
SANY grader gd511
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
nude packing
Port
Shanghai
Product Description

 GR180 Motor Grader for sale!!!

 Main Features:



Engine model: 6CTAA8.3 D6114
Rated power/speed: 138/2200kw/rpm
Dimension(LxWxH) : 6880×2375×3150mm
Operating weight(Standard): 15400kg









Basic specification

Engine model6CTAA8.3 D6114
Rated power/speed138kW/2200  140kW/2300rpm
Dimension(LxWxH)8900×2625×3470mm
Operating weight(Standard)15400kg

Performance specification

Travelling speed ,forward5,8,11,19,23,38 km/h
Travelling speed ,reverse5,11,23 km/h
Tractive force(f=0.75)79KN
Max. gradeability20%
Tire inflation pressure260 kPa
Working hydraulic pressure16 MPa
Transmission pressure1.3~1.8MPa

Operating specification

Max. steering angle of front wheels±50°
Max. lean angle of front wheels±17°
Max. oscillation angle of front axle±15°
Max. oscillation angle of balance box15
Frame articulation angle±27°
Min. turning radius using articulation7.3m
Biade
Maximum lift above ground450mm
Maximum depth of cutting500mm
Maximum blade position angle90°
Blade cutting angle28°—70°
Circle reversing rotation360°
Moldboard width X height3965×610mm
