Lonking LG80DT chinese forklift spare parts

FOB Reference Price:Get Latest Price
$9,000.00 - $10,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
LG80DT
Rated Loading Capacity:
8t
Lead Time:
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 Negotiable
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Warranty:
1 year
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Place of Origin:
Shanghai, China
Brand Name:
lonking
Certification:
ISO
Overall Dimensions:
5486*2230*2850mm
Power Souce:
Diesel Engine
Fork Length:
1070mm
Fork Width:
1070mm
Max. Lifting Height:
3000mm
Min. Lifting Height:
3000mm
Engine Model:
YC6B125
Rated Power:
92kw
Min. Turning Radius:
3680mm
Max. Gradeability (with load):
20%
Dead Weight:
10500kg
Other Character:
forklift spare parts
Type:
Powered Pallet Truck
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
nude packing
Port
Shanghai
Lead Time :
Quantity(Sets) 1 - 1 >1
Est. Time(days) 30 To be negotiated





Product Description

LONKING Forklift Small Lifting Capacity Foklift



Max.Lifting Capacity: 8t

Max. Lifting Height: 3000mm

Engine Model: Yuchai  YC6B125

Rated Power: 92kw






MODELLG80DT
Power typeDiesel
Rated capacity (Kg)8000
J Load centre (mm)                                    600
h1 STD Max lifting height (mm)3000
h3 Free lifting height (mm)200
L5*W*T STD Fork size (mm)1520×175×85
Mast tilt angle (deg)6/12
L3 Front overhang (mm)706
L4 Rear overhang (mm)780
Overall dimension
L1 Overall length(mm)5486
W1Overall width (mm)2230
h2 Mast lowered height (mm)2850
h4 Overhead guard height (mm)2595
R1 Min.turning radius (mm)3680
Min .intersecting aisle (mm)5600
Speed(load/unload)
Max.traveling speed (km/h)(F/R)27/27
Max,lifting speed (mm/s)(load/unload)310/450
Max.gradient (%)20
Dead weight (kg)10500
S/P Tread(frnt/rear)(mm)1600/1700
L2 Axle distance (mm)2500
Min.ground clearance
m2 Mast (mm)240
m1 Frame (mm)280
STD EngineYuchai  YC6B125
Rated power(kw)92
