5ton Lonking LG50DT forklift with cheap spare parts

FOB Reference Price:Get Latest Price
$8,900.00 - $11,000.00 / Set | 1 Set/Sets (Min. Order)
Model Number:
LG50DT
Rated Loading Capacity:
5t
Shipping:
Support Sea freight
Report Suspicious Activity
Overview
Quick Details
Condition:
New
Warranty:
1 year
After-sales Service Provided:
Field installation, commissioning and training, Engineers available to service machinery overseas
Place of Origin:
Shanghai, China
Brand Name:
lonking
Certification:
ISO
Overall Dimensions:
4705*2000*2500mm
Power Souce:
Diesel Engine
Fork Length:
1070mm
Fork Width:
1070mm
Max. Lifting Height:
3000mm
Min. Lifting Height:
3000mm
Engine Model:
CA6110/125G2
Rated Power:
83kw
Min. Turning Radius:
3415mm
Max. Gradeability (with load):
20%
Dead Weight:
8082kg
Other Character:
forklift spare parts
Type:
Powered Pallet Truck
Supply Ability
Supply Ability:
100 Set/Sets per Month
Packaging & Delivery
Packaging Details
nude packing
Port
Shanghai





Product Description

LONKING Forklift Small Lifting Capacity Foklift



Max.Lifting Capacity: 5t

Max. Lifting Height: 3000mm

Engine Model: Xichai CA6110/125G2

Rated Power: 83kw






MODELLG50DT
Power typeDiesel
Rated capacity (Kg)5000
J Load centre (mm)                                    600
h1 STD Max lifting height (mm)3000
h3 Free lifting height (mm)200
L5*W*T STD Fork size (mm)1220×150×60
Mast tilt angle (deg)6/12
L3 Front overhang (mm)590
L4 Rear overhang (mm)645
Overall dimension
L1 Overall length(mm)4705
W1Overall width (mm)2000
h2 Mast lowered height (mm)2500
h4 Overhead guard height (mm)2464
R1 Min.turning radius (mm)3415
Min .intersecting aisle (mm)5400
Speed(load/unload)
Max.traveling speed (km/h)(F/R)27/27
Max,lifting speed (mm/s)(load/unload)330/450
Max.gradient (%)20
Dead weight (kg)8082
S/P Tread(frnt/rear)(mm)1470/1700
L2 Axle distance (mm)2250
Min.ground clearance
m2 Mast (mm)216
m1 Frame (mm)248
STD EngineXichai CA6110/125G2
Rated power(kw)83
